Shaft Insert Strengthner

3

Eastwood8787
Entry ID #: 6671
Created: Tue, Jan 15, 2019 12:54 PM


EASTWOOD ROBOTICS
TEAM 8787A

PRESENTS:

THE SHAFT INSERT STRENGTHENER



One recurring problem has haunted our teams building abilities while preparing for VRC competition. The shaft inserts within wheels and geers experience excess strain and torque over time, as a result our wheels have become striped and impossible to reuse. This problem caused shafts to free spin and un-effectively turn the vital components we need. The amount of wheels we've had to scrap due to this pushed us to find solutions.

Links / Videos

Shaft Insert Strengthener CAD Video
